Brand Name:
Greef
Certification:
CE
Model Number:
3KW - 110KW
| Attribute | Value |
|---|---|
| Rated Power | 3kW-110kW |
| Ingress Protection | IP66 |
| MPPT Efficiency | 99.9% |
| Rated Output Voltage | 380V |
| Warranty | 5 Years |
| Output Voltage Range | 220Vac - 540Vac |
| Temperature Protection | Yes |
| Rated Frequency | 50Hz / 60Hz |
INVT grid-connected inverter products deliver outstanding performance in PV systems through advanced technological features:
| Model | XG1KTL-S | XG2KTL-S | XG3KTL-S | XG4KTL-S | XG5KTL-S |
|---|---|---|---|---|---|
| Input (DC) | |||||
| Max. Input Power | 1.5kW | 3kW | 4.5kW | 6kW | 7.5kW |
| Max. Input Voltage | 600V | ||||
| Start Voltage | 60V | ||||
| Output (AC) | |||||
| Max. Output Current | 5A | 10A | 15A | 20A | 22.7A |
| Rated Output Power | 1kW | 2kW | 3kW | 4kW | 5kW |
| Rated Grid Frequency | 50Hz / 60Hz | ||||
| MPPT Efficiency | 99.90% | ||||
Ideal for industrial, commercial, and residential applications, supporting clean energy projects with high efficiency and low-carbon development goals.
The inverter is securely packaged in sturdy cardboard with foam inserts for protection during transit. Each unit is wrapped in plastic to prevent moisture damage.
Orders ship within 1-2 business days via reliable carriers with tracking provided. We ensure safe and timely delivery of your product.
