Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery

Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery

280AH OFF GRID TIED System

RS485 ON GRID TIED System

Customizable OFF GRID TIED System

Place of Origin:

CHINA

Brand Name:

GREEF

Certification:

ce

Model Number:

Lithium Battery

Contact Us
Request A Quote
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery
Product Details
Nominal Voltage:
51.2V-1485V
Nominal Capacity:
50AH-200AH
Storage Type:
Solar Energy
Communication Port:
RS485,CAN
Payment & Shipping Terms
Minimum Order Quantity
1set
Price
Negotiable
Packaging Details
Carton or Plywooden Case
Delivery Time
25-30 Working Days
Payment Terms
T/T, Western Union, L/C
Supply Ability
400 Sets per Month
RELATED PRODUCTS
Good price Remote Control Hybrid Solar System for 230vac single-phase Output Voltage and LCD Panel online Video

Remote Control Hybrid Solar System for 230vac single-phase Output Voltage and LCD Panel

Get Best Price
Good price 5kW Solar Wind Hybrid Generator with LCD Panel Control 10kw Solar System online Video

5kW Solar Wind Hybrid Generator with LCD Panel Control 10kw Solar System

Get Best Price
Good price Remote Control Hybrid Solar and Wind System and 98% Efficiency online Video

Remote Control Hybrid Solar and Wind System and 98% Efficiency

Get Best Price
Good price Pure Sine Wave Hybrid Solar System with 98% Efficiency and 230vac Rated Output Voltage online Video

Pure Sine Wave Hybrid Solar System with 98% Efficiency and 230vac Rated Output Voltage

Get Best Price
Contact Us
Contact Now
Product Description

Multi-Model Customizable ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery

Product descriptions from the supplier








Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 0
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 1
Model
L5160
L51100
L51200
L51280
Rated Voltage (V)
51.2V
Rated Capacity (Ah)
60Ah
100Ah
200Ah
280Ah
Rated Energy (Wh)
3072Wh
5120Wh
10240Wh
14336Wh
Voltage Range (V)
43.2-58.4V
Greer Voltage Range (V)
56-58.4V
Cut-off Voltage (V)
43.2V
Recommend Charge Current (A)
≤30A
≤50A
≤100A
≤140A
Max Charge Current (A)
36A
60A
120A
168A
Recommend Discharge Current (A)
≤30A
≤50A
≤100A
≤140A
Max Discharge Current (A)
60A
100A
200A
280A
Communication Port
RS485,CAN
Display
LED
Address range
0-63
IP
IP20
Humidity (%)
5-95% RH
Storage Temperature Range ('C)
-20~45°C SOC:20%~50%
Cooling mode
Intelligent Fan-cooling temperature control
Cycle Life
26000 (0.5c@25℃,80%DOD)
Energy efficiency
≥98%
Safety & Certification
CE (EMC:EN61000-6-1) CB (TUV: IEC62619) RoHS (2011/65/EU)
Transportation
UN38.3,MSDS
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 2
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 3
Model
HS5160-2
HS5160-3
HS5160-4
HS5160-5
HS5160-6
HS5160-7
Rated Voltage (V)
102.4V
153.6 V
204.8 V
256 V
307.2 V
358 V
Module Number
2
3
4
5
6
7
Rated Energy (wh)
6144 Wh
9216 Wh
12288 Wh
15360 wh
18432 Wh
21480 Wh
Rated Capacity (Ah)
60Ah
Recommend Charge Current (A)
≤30A
Max Charge Current (A)
36A
Recommend Discharge Current (A)
≤30A
Max Discharge Current (A)
60A
Communication Port
RS485,CAN
Display
LED
IP
IP55
Humidity (%)
5-95% RH
Storage Temperature Range (°C)
-20~45°CSOC:20%~50%
Installation Method
Floor-mounted
Cycle Life
≥6000 (0.5C@25℃,80%DOD)
Energy effi ciency
≥98%
Safety & Certification
CE (EMC: EN61000-6-1 CB (TUV: IEC62619) RoHS (2011/65/EU)
Transportation
UN38.3,MSDS
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 4
Model
HS51100-2
HS51100-3
HS51100-4
HS51100-5
HS51100-6
HS51100-7
Rated Voltage (V)
102.4V
153.6 V
204.8 V
256 V
307.2 V
358 V
Module Number
2
3
4
5
6
7
Rated Energy (wh)
10240Wh
15360Wh
20480 Wh
25600 wh
30720 Wh
35800 Wh
Rated Capacity (Ah)
100Ah
Recommend Charge Current (A)
≤50A
Max Charge Current (A)
60A
Recommend Discharge Current (A)
≤50A
Max Discharge Current (A)
100A
Communication Port
RS485,CAN
Display
LED
IP
IP55
Humidity (%)
5-95% RH
Storage Temperature Range (°C)
-20~45°CSOC:20%~50%
Installation Method
Floor-mounted
Cycle Life
≥6000 (0.5C@25℃,80%DOD)
Energy effi ciency
≥98%
Safety & Certification
CE (EMC: EN61000-6-1 CB (TUV: IEC62619) RoHS (2011/65/EU)
Transportation
UN38.3,MSDS
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 5
Model
HESS300 35KWh-70KWh
HESS800 75KWh-150KWh
HESS1500 150KWh-300KWh
Rated Voltage (V)
358.4V
768V
1485V
Voltage Range (V)
330.4~397.6V
708~852V
1368.8~1647.2V
Module Number
7
7
15
15
29
29
Rated Energy (wh)
35.8KWh
71.6KWh
76.8KWh
153.6KWh
148.5KWh
297KWh
Rated Capacity (Ah)
100Ah
200Ah
100Ah
200Ah
200Ah
200Ah
Recommend Charge Current (A)
≤50A
≤100A
≤50A
≤100A
≤50A
≤100A
Max Charge Current (A)
60A
120A
60A
120A
60A
120A
Recommend Discharge Current (A)
≤50A
≤100A
≤50A
≤100A
≤50A
≤100A
Max Discharge Current (A)
100A
200A
100A
200A
100A
200A
Display
LED
IP
IP20
Humidity (%)
5-95% RH
Storage Temperature Range (°C)
-20~45°CSOC:20%~50%
Installation Method
Floor-mounted
Communication Port
RS485,CAN
Cycle Life
≥6000 (0.5C@25℃,80%DOD)
Energy effi ciency
≥98%
Safety & Certification
CE (EMC: EN61000-6-1 CB (TUV: IEC62619) RoHS (2011/65/EU)
Transportation
UN38.3,MSDS
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 6
Model
RESS-5KWH-51.2V/100A
Nominal Voltage[V]
51.2
Nominal Capacity [Ah]
100
Total Energy [Wh]
5.12
Max.Charging Current[A]
100
Max. Discharging Current [A]
100
Pulse Discharge Current
120A@10 min 150A @1min
Charging Voltage [V]
55.2~57.6
End of Dicharge Voltage [V]
44.8(Backup Application) / 48(Cycle Application)
Operation Humidity
0~95% RH(No condensing)
Operating Temperature Range
Standard Product: Charge: 0~+55C,Discharge:-20 ~+55C With Optional Heater: Charge /Discharge:-30~+55C
Cycle Life
>6000
Communication interface
RS485,CAN for inverterLink -in & Link-out for battery to battery communication
Protection
Over voltageLow voltage. Over current.Over Temperature, Low Temperature, Short circuit
Parallel Support
Yes,Max.15 Sets
Optional Part
Bluetooth Module.Heater parts(200W),Distribution box (for parallel connection)
Multi Model ON/OFF GRID TIED System Fast Response Time 60-280AH Lithium Battery 7
Model
HV RESS- 72
Battery Module
51.2V 72Ah(3.68KWH)
Number of Battery Modules
4
5
6
7
8
Total Energy [kWh]
14.7
18.4
22.0
25.7
29.4
Nominal Voltage[Vdc]
204.8
256
307.2
358.4
409.6
Voltage Range [Vdc]
160~240
200~300
240~360
280~420
320~480
Max. Charging Current [A]
50
Max. Discharging Current [A]
50
Pulse Discharge Current
100A/10s
MaxInverter Power[W]
10000
12800
15360
17920
20480
Operating Temperature Range
Charge:0~+55°C;Discharge:-20~+55C
Operation Humidity











Model
HV RESS- 100
Battery Module
51.2V 100Ah(5.12KWH)
Number of Battery Modules
4
5
6
7
8
Total Energy [kWh]
20.5
25.6
30.7
35.8
40.9
Nominal Voltage[Vdc]
204.8
256
307.2
358.4
409.6
Voltage Range [Vdc]
160~240
200~300
240~360
280~420
320~480
Max. Charging Current [A]
50
Max. Discharging Current [A]
50
Pulse Discharge Current
100A/10s
MaxInverter Power[W]
10000
12800
15360
17920
20480
Operating Temperature Range
Charge:0~+55°C;Discharge:-20~+55C
Operation Humidity
0~95% RH(No condensing)
Communication interface
CAN*1,DI*1,DO*2

Advantages of Lithium Batteries

1. High energy density: The high energy density of lithium batteries can provide more power, enabling new energy turbines to operate more efficiently. 2. Long service life: The long service life of lithium batteries reduces the frequency of battery replacement, thus reducing maintenance costs. 3. Good safety: Compared to other types of batteries, lithium batteries have better safety performance, which can effectively prevent fire and other accidents. 4. Fast response time: Lithium batteries have a fast response time and can quickly provide the required electrical energy, enabling new energy turbines to start and stop faster. 5. Environmentally friendly: Lithium batteries are an environmentally friendly type of battery that does not pollute the environment.
