Brand Name:
Greef
Certification:
CE
Model Number:
TYP
TYP Magnet motors are equipped with rotors that contain permanent magnets. This advanced design brings several key benefits to the motors.
One of the main advantages of this technology is the improved efficiency it delivers. Additionally, these motors offer a higher power density relative to their frame size, making them more compact yet powerful.
These motors operate with the help of frequency inverters, which maintain a constant torque over a broad speed range. This capability allows the motors to perform efficiently even at low speeds, outperforming traditional induction motors. Moreover, they achieve these efficiency levels without the need for forced ventilation, enhancing their reliability and reducing maintenance requirements.
W21 Magnet motors are specifically designed for applications requiring low speed operation with minimal noise. They also focus on energy conservation, making them an excellent choice for environmentally conscious and cost-effective solutions.
This motor saves up to 30% more energy compared to traditional induction motors powered by inverters. It operates with high efficiency over a wide load range, from 20% to 110% of the rated load, achieving measured energy savings between 10% and 40%.
Additionally, it maintains an exceptionally high power factor, close to 1.0 when operating at rated conditions, and always above 0.95. This feature minimizes stator current and reduces copper losses, enhancing overall performance.
The motor delivers a consistent torque throughout a broad speed spectrum without the need for forced ventilation. This makes it ideal for applications that require speed variation and constant torque, including operation at low speeds, all without the necessity of an encoder.
Equipped with bearings that have an L10 life expectancy of up to 100,000 hours, equivalent to over 10 years of continuous use, the motor ensures long-lasting reliability. Furthermore, grease nipples are fitted to allow re-lubrication, which helps minimize maintenance downtime.
This motor utilizes powerful NdFeB (Neodymium/Iron/Boron) rare-earth magnets, which are about 18 times stronger than conventional ferrite magnets. The magnets are coated with a protective epoxy layer, providing enhanced mechanical strength and excellent resistance to corrosion.
Positive Temperature Coefficient (PTC) thermistors are embedded within the windings, offering complete protection against overheating caused by phase loss, overload, and voltage irregularities such as under- or overvoltage.
As a synchronous motor, the rotor speed precisely matches the stator's rotating magnetic field speed, eliminating slip and rotor power losses. The motor maintains a stable speed that is unaffected by voltage fluctuations or load changes, resulting in improved control accuracy.
Utilizing a maximum torque to current ratio control mode, the motor achieves a high power factor across its full speed range. This approach significantly lowers the stator current by 15% to 30%, which reduces cable transmission losses and effectively increases the cable’s load capacity.
Thanks to its high efficiency and minimized losses, the motor’s temperature rise is 15 to 20°C lower compared to equivalent asynchronous motors operating under the same conditions.
This motor is widely applied across various industries, including injection molding machines, air compressors, pipe making equipment, hydraulic machinery, food processing machines, extruders, wire drawing machines, and pharmaceutical equipment. It is important to use it together with a dedicated permanent magnet motor inverter.
Switching from a 37kW IE2 (GB3) induction motor to this motor can result in substantial energy savings, approximately 9,000 RMB annually, assuming continuous 24/7 operation.
The TYP series of high-efficiency permanent magnet synchronous motors with frequency conversion technology are highly versatile and reliable. These motors are engineered to deliver exceptional performance across a wide range of applications.
They are extensively utilized in various industries, including injection molding machines, air compressors, and pipe making equipment. Their robust design makes them suitable for demanding environments and ensures consistent operation.
Additionally, these motors find applications in hydraulic machinery, food processing equipment, cement pipe manufacturing machines, plastic extruders, wire drawing machines, and pharmaceutical devices. Their adaptability and efficiency make them an ideal choice for these specialized fields.
Greef offers comprehensive product customization services for our Permanent Magnet Motor, model TYP, proudly made in China. Certified with CE, this electromechanical motor is designed to deliver exceptional performance with low noise operation, making it ideal for applications in electric vehicles, robotics, and industrial automation.
Our Permanent Magnet Motor features a 6-pole design and utilizes high-quality NdFeB magnets combined with SKF bearings to ensure durability and efficiency. We specialize in customizable low speed motor solutions tailored to meet your specific requirements.
With a minimum order quantity of just 1 set, pricing is negotiable to accommodate your project needs. Each motor is carefully packaged using foam and plywooden cases to guarantee safe delivery within 25 working days.
Payment terms are flexible, accepting T/T, Western Union, MoneyGram, and L/C. Our supply ability ensures reliable and timely fulfillment for your orders.
Trust Greef to provide a premium, low noise, and customizable electromechanical motor solution that perfectly fits your industrial demands.
Our Permanent Magnet Motors are carefully packaged to ensure maximum protection during transit. Each motor is securely wrapped in anti-static foam and placed inside a sturdy, custom-fitted cardboard box to prevent any movement or damage.
For added safety, the packaged motors are then placed in reinforced shipping cartons with additional cushioning materials. All packages are clearly labeled with handling instructions and product details to facilitate smooth delivery.
We offer various shipping options to meet your needs, including standard, expedited, and freight services. Each shipment is tracked and monitored until it reaches your specified destination, ensuring a reliable and timely delivery experience.
Before shipping, every motor undergoes a thorough quality inspection and testing process to guarantee optimal performance upon arrival. Our packaging and shipping procedures comply with international standards to protect your investment and provide peace of mind.
