48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban

48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban

Large Image :  48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban

Product Details:
Place of Origin: QINGDAO
Brand Name: GREEF
Certification: CE
Model Number: AH-30KW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 25DAY
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 25
Detailed Product Description
Type: Wind Power Generator,50kw To 500KW Permanent Magnet Alternator Rated Voltage: 12V / 24V / 48V
Application: HAWT Warranty: 3 Years
Portection Grade: IP 54 Material: Customized Material
Tolerance: +/-0.1mm Or According To Customer Request
High Light:

Horizontal Axis Pitch Wind Turbine

,

HAWT Pitch Control Wind Turbine

,

48V Pitch Control Wind Turbine

Horizontal Axis Wind Turbine Catalogue

Model: 30KW Horizontal axis wind turbine |Off-grid system |on-grid system| Folding tower

GREEF AH-30KW wind generator is the conversion of wind energy into mechanical energy first and electric energy afterwards. Thisequipment can fully make use of wind power to recharge a battery, and also can saved energy into ac source alternating current.Without the necessity of fuel, the AH-30KW wind generator is pollution free and far away from noise. The AH-30KW wind generator isgenerally applicable to the area which has good condition but is far away from the power grid, or the power grid is not normal.The AH-30KW generator can supply lighting, the television set, the searchlight, the communication equipment, the power tool andother household appliances.
Recommended for:
· Household,Garden,Farm,Urban ,Rooftop
· Telecom sites.
· Rural electrification programs. Island , sentry, island, sight lighting
· Automatic speed reduction protection
Technical specification
Model
AH-30KW
Rated Power
30KW
Max Power
35KW
Start Wind Speed
2.5m/s(6.72mph)
Rated Wind Speed
11m/s(22.4mph)
Working Wind Speed
3-30m/s(8.96-56 mph)
Safety Wind Speed
60m/s(112mph)
Blades Rotor Diameter
13.1M(17.7ft)
Blades Material &Quantity
FRP /3PCS
Top Weight
2800kg
Tower Height
≥20m(26.24ft.) Free folding tower
Generator Type
Free stand tower
Rated voltage
450RPM
Rated rotating speed
95RPM
Speed regulation method
Auto yawing+pitch-controlled
Wind answering method
Up wind+yawing
Working Temperature
-20℃~+50℃
Products Description
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 0
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 1
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 2
More products
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 3
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 4
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 5
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 6
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 7
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 8
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 9
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 10
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 11
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 12
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 13
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 14
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 15
Systems
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 16
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 17
Why Choose Us
We are global supplier which focus on Permanent Magnet generator, wind turbine , wind turbine blades, controller, invertor etc.
"GREEF" have its own engineer design team which is design products ourselves. Moreover, we have successfully obtained CE approvals and supports from our customers, which boost our business day by day!
Believe in us, we can accompany you forever.48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 18
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 19
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 20
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 21
48V HAWT Horizontal Axis Pitch Control Wind Turbine For Urban 22
