Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw

Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw

Large Image :  Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw

Product Details:
Place of Origin: QINGDAO
Brand Name: GREEF
Certification: CE
Model Number: AH-5KW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $299-12999
Packaging Details: Inner Foam + Plywooden case
Delivery Time: 25DAY
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 12
Contact Now
Detailed Product Description
Name: Pitch Control Wind Turbine Model Rotor Diameter(m): 5.6
Blade Material & Qty.: FRP*3 Rated Power(kW): 5
Rated Wind Speed(m/s): 11 Rated Rotating Speed(r/min): 240
High Light:

1kW Pitch Control Wind Turbine

,

Horizontal Axis Pitch Control Wind Turbine

,

25m/S Low Speed Dc Generator

5kW Low Start Wind Speed Pitch Control Horizontal Axis Wind Turbine1kw Magnet Generator Price For Home

Why choose AH-5KW wind turbine?



Leading technology-intelligent control, strong system scalability
1. The world's best wind power control technology is combined with the self-developed variable pitch technology.
2. The hardware design uses international well-known brands, and the software uses redundant control strategies.
3. It can achieve good compatibility with various well-known brand converters and remote modules.

High security-continuous operation around the clock to achieve unattended operation
1. The speed of the wind wheel is controlled, and it runs continuously and stably under severe wind conditions.
2. More than a dozen redundant control strategies ensure the safety and stability of the system in all climates.

A lot of power generation-variable pitch control, high-efficiency output, power generation up to 30%
1. Above the rated wind speed, the pitch angle of the blades can be adjusted to achieve continuous full power output.
2. The working wind speed range is large (3-25m/s), and the effective running time is long.
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 0
Recommended for:
· Household,Garden,Farm,Urban ,Rooftop
· Telecom sites.
· Rural electrification programs. Island , sentry, island, sight lighting
· Automatic speed reduction protection
Technical specification
Model
AH-5KW
Rotor diameter(m)
5.6
Blade material & Qty.
FRP*3
Rated power(kW)
5
Rated wind speed(m/s)
11
Rated rotating speed(r/min)
240
Generator type
3-phase PMG
Working wind speed(m/s)
3-30
Start-up wind speed(m/s)
2.5
Survival wind speed(m/s)
60
Rated voltage(VDC)
400/240/custom made
Speed regulation method
Pitch-controlled
Wind answering method
Up wind
Stop method
Auto brake
Gale protection
Smart control+unattended
weight(kg)
400
Noise level(dB)
≤65
Tower height(m)
≥8
Tower model
Tilt-up tower
Working temperature
-20℃～+50℃
Products Description
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 1
Using the world's leading mechanical centrifugal variable pitch technology, the average annual power generation is 30% more.
(1) Large initial blade angle (+9 ), excellent acceleration performance, start at low wind speed of 2.5m/s;
(2) Below the rated wind speed, the wind turbine outputs efficiently;
(3) Above the rated wind speed, adjust the pitch angle so that the rotor speed is maintained near the rated speed and the power output is stable.
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 2
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 3
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 4
Project case

25kW Wind-solar-diesel Complementary Power Supply Project at Barracks of Garrison on Yongxing Island of Paracel Islands


Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 5
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 6

New Energy Power Supply System at Communication Base Stations in Danish


Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 7
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 8

On-grid Systems in Other Countries

The systems were also installed in countries, like India, the Phillipines, Ireland, Colombia,France, Brazil, Swiss and Hungary.
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 9
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 10
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 11
Systems
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 12
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 13
Low Start Wind Speed Pitch Control Wind Turbine Horizontal Axis 5kW 1kw 14
