20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home

20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home

Large Image :  20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home

Product Details:
Place of Origin: QINGDAO
Brand Name: GREEF
Certification: CEC
Model Number: AH-5KW-30KW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Inner Foam + Plywooden case
Delivery Time: 25DAY
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 25 Units
Detailed Product Description
Type: Wind Power Generator Rated Power: 300w-30kw
Rated Voltage: 12V / 24V / 48V Generator Type: 3 Phase AC Permanent-magnet,Three Phase AC Permanent Magnet Synchronous Generator,1-3kw Vertical Axis Wind Turbine
Application: Electricity Generation Warranty: 2 Years
Portection Grade: IP 54 Color: Multicolor
Tolerance: +/-0.1mm Or According To Customer Request Life Time: 20 Years
Size: Customized Magnet Size Rated Rotor Speed: 20-900RRM
Generator: 3-Phase Permanent Magnet Generator AC Alternator
High Light:

20kW Horizontal Axis Wind Turbine

,

Pitch Control Horizontal Axis Wind Turbine

,

20kW hawt wind turbine

20kW low start wind speed pitch control horizontal axis wind turbine magnet generator price for home

Why choose AH-20KW wind turbine?



Leading technology-intelligent control, strong system scalability
1. The world's best wind power control technology is combined with the self-developed variable pitch technology.
2. The hardware design uses international well-known brands, and the software uses redundant control strategies.
3. It can achieve good compatibility with various well-known brand converters and remote modules.

High security-continuous operation around the clock to achieve unattended operation
1. The speed of the wind wheel is controlled, and it runs continuously and stably under severe wind conditions.
2. More than a dozen redundant control strategies ensure the safety and stability of the system in all climates.

A lot of power generation-variable pitch control, high-efficiency output, power generation up to 30%
1. Above the rated wind speed, the pitch angle of the blades can be adjusted to achieve continuous full power output.
2. The working wind speed range is large (3-25m/s), and the effective running time is long.
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 0
Recommended for:
· Household,Garden,Farm,Urban ,Rooftop
· Telecom sites.
· Rural electrification programs. Island , sentry, island, sight lighting
· Automatic speed reduction protection
Technical specification
Model
AH-20KW
Wind rotor diameter (m)
9.8
Blade material and quantity
Fiber glass reinforced * 3
Rated power (w)
20,000
Rated wind speed (m/s)
11
Rated rotate speed (rpm)
175
Working wind speed (m/s)
3-25
Start up wind speed (m/s)
2.5
Survived wind speed (m/s)
59.5
Working voltage (v)
DC450V
Speed regulation method
Pitch control + Active yawing +electromagnet brake
Stop method
Pitch controlled brake +Active yawing
Generator style
Three phase, permanent magnet
Wind turbine weight (kg)
1210
Products Description
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 1
Using the world's leading mechanical centrifugal variable pitch technology, the average annual power generation is 30% more
(1) Large initial blade angle (+9 ), excellent acceleration performance, start at low wind speed of 2.5m/s;
(2) Below the rated wind speed, the wind turbine outputs efficiently;
(3) Above the rated wind speed, adjust the pitch angle so that the rotor speed is maintained near the rated speed and the power output is stable.
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 2
Project case

20kW In France


20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 3
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 4

20kW In Kashgar


20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 5
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 6



Systems
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 7
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 8
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 9
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 10
Why Choose Us
We are global supplier which focus on Permanent Magnet generator, wind turbine , wind turbine blades, controller, invertor etc.
"GREEF" have its own engineer design team which is design products ourselves. Moreover, we have successfully obtained CE approvals and supports from our customers, which boost our business day by day!
Believe in us, we can accompany you forever.
20kW Low Start Speed Pitch Control Horizontal Axis Wind Turbine Magnet Generator For Home 11
