5kw Home Small Grid-Tied Horizontal Wind Turbine Generator System

Name: 5kw Home Small Grid-Tied Horizontal Wind Turbine Generator System
Brand: GREEF
SKU: AH-5KW
Price: 299 USD
Availability: InStock
Rating: 5 (176 reviews)

Large Image : 5kw Home Small Grid-Tied Horizontal Wind Turbine Generator System

Product Details:

Place of Origin:	CHINA
Brand Name:	GREEF
Certification:	CE
Model Number:	AH-5KW

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	$299-12999
Packaging Details:	Inner Foam + Plywooden case
Delivery Time:	25DAY
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	25 Units

Contact Now

Detailed Product Description

Rated Power:	300w-30kw	Type:	Wind Power Generator
Application:	Electricity Generation	Rated Voltage:	12V / 24V / 48V
Portection Grade:	IP 54	Color:	Multicolor
Tolerance:	+/-0.1mm Or According To Customer Request	Warranty:	2 Years
Size:	Customized Magnet Size	Rated Rotor Speed:	20-900RRM
High Light:	5kw Horizontal Wind Turbine Generator , Grid-Tied Horizontal Wind Turbine Generator , 5kw horizontal axis small wind turbine

5kw Home High Quality Small Grid-tied Horizontal Wind Turbine Generator System

Technical specification

Model	AH-5KW
Rotor diameter(m)	5.6
Blade material & Qty.	FRP*3
Rated power(kW)	5
Rated wind speed(m/s)	11
Rated rotating speed(r/min)	240
Generator type	3-phase PMG
Working wind speed(m/s)	3-30
Start-up wind speed(m/s)	2.5
Survival wind speed(m/s)	60
Rated voltage(VDC)	400/240/custom made
Speed regulation method	Pitch-controlled
Wind answering method	Up wind
Stop method	Auto brake
Gale protection	Smart control+unattended
weight(kg)	400
Noise level(dB)	≤65
Tower height(m)	≥8
Tower model	Tilt-up tower
Working temperature	-20℃～+50℃

Products Description

Using the world's leading mechanical centrifugal variable pitch technology, the average annual power generation is 30% more.

(1) Large initial blade angle (+9 ), excellent acceleration performance, start at low wind speed of 2.5m/s; (2) Below the rated wind speed, the wind turbine outputs efficiently;
(3) Above the rated wind speed, adjust the pitch angle so that the rotor speed is maintained near the rated speed and the power output is stable.

Project case

25kW Wind-solar-diesel Complementary Power Supply Project at Barracks of Garrison on Yongxing Island of Paracel Islands

New Energy Power Supply System at Communication Base Stations in Danish

On-grid Systems in Other Countries

The systems were also installed in countries, like India, the Phillipines, Ireland, Colombia,France, Brazil, Swiss and Hungary.
