Place of Origin:
Qingdao
Brand Name:
Greef
Certification:
CE
Model Number:
PERMANENT MAGNET GENERATOR
Document:
Video
Video
| Attribute | Value |
|---|---|
| Cooling Method | Air Cooling |
| Rated Frequency | 50Hz/60Hz |
| Application | Electricity Generation |
| Rated Rotate | 20rpm-3000rpm |
| Rated Speed | 3000rpm |
| Rated Voltage | Customized |
| Rated Power | 10kW |
| Power Range | 500W-5000kW |
The Permanent Magnet Generator is a high-performance, durable and efficient electrical generator that utilizes advanced technology for a wide range of applications. It is designed to provide reliable power supply in various industries such as renewable energy, transportation, and industrial manufacturing.
| Parameter | Value |
|---|---|
| Rated power | 0.5-5000kW |
| Rated rotate speed | 20-3000rpm |
| Rated voltage | 48-1140Vac |
| Frequency | 60/50Hz |
| Number of Poles | 24 |
| Generator type | 3phase AC Synchronous generator |
| Magnet type | NdFeB |
| Winding Method | Y |
| Magnet temperature level | Max.120℃ |
| Winding temperature level | Max.180℃ |
| Efficiency | >95% |
| Insulate Grade | H |
| Insulating resistance | 100Mohm Min(500Vdc) |
| Classification of degrees | IP54 |
| Generator shell material | Cast Iron |
| Winding material | 100% Copper |
| Shaft material | Steel |
| Iron Core | Cold rolled silicon steel sheet |
| Bearing brand | SKF |
| Cooling Method | Fan Cooling |
| Weight (N.W /G.W ) | 132kg /152kg |
| Packing Size | 870*470*570mm |
