Name: AHCC Off Grid Controller 40Aac MPPT 90-520V RS485/TCP
Brand: Qingdao Greef New Energy Equipment Co., Ltd
SKU: AHCC
Price: 12399.00 USD
Availability: InStock

Home > products > Off Grid Controller >

AHCC Off Grid Controller 40Aac MPPT 90-520V RS485/TCP

40A MPPT off grid controller

off grid controller with RS485

520V solar charge controller

Brand Name:

Greef

Certification:

Model Number:

AHCC

Request A Quote

Product Details

Rated Unloading Current:

40Adc/50Adc/100Adc

Model:

AHCC

Rated Input Current:

40Aac/80Aac

Nominal System Voltage:

42-240Vdc/200-1000Vdc (parameters Adjustable Depending On Type Of Energy Storage)

Communication Interface:

Standard: RS485/TCP

Application:

Solar System Or Wind Turbine Or Generator System

Battery Type:

Lead-acid Batteries, Lithium Batteries, DC Bus Bars, Etc.

MPPT Voltage Range:

90~520V Customized/220~530Vac

Payment & Shipping Terms

Minimum Order Quantity

1Set

Price

Negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

Payment Terms

T/T,Western Union,MoneyGram,L/C

Supply Ability

High Frequency Isolated Energy Converter off grid Controller for Sustainable Off-Grid Solutions

Get Best Price

Video

Lightning Protection Circuits Off Grid Controller Maximum Withstand Voltage 290Vac-530Vac/600Vac For 5 Seconds

Get Best Price

Video

Controller for Greef MPPT Technology Rated voltage 48Vac-380Vac

Get Best Price

Video

5KW/10KW/20KW/30KW Rated Power Off Grid Controller 100A/200A/80A/150A Rated Output Current PWM/MPPT Method

Get Best Price

Contact Now

Product Description

MPPT Voltage Range 90-520V Customized/220-530Vac Off Grid Controller Featuring Lightning Protection Circuits

Product Overview

The Off-grid Controller is an essential component in wind generator systems, converting three-phase AC current from wind turbines into DC current to charge battery banks. The GREEF wind off-grid controller features advanced MPPT technology for enhanced electricity production, along with modular design, electrical isolation, PWM unloading, and host computer control.

The controller includes a user-friendly interface with large touchscreen and IoT functionality for efficient, safe, and intelligent power generation management.

Applications

The AHCC Off-Grid Controller is compatible with various renewable energy systems:

Off-grid wind power generation systems
Off-grid hydroelectric power generation systems
Off-grid solar power generation systems

Technical Specifications

Model	AHCC-5KW	AHCC-10KW	AHCC-20KW	AHCC-30KW
Rated power	5KW	10KW	20KW	30KW
Product Type	MPPT, high frequency isolated new energy converter
DC Output Side
Type of energy storage	Lead-acid batteries, lithium batteries, DC bus bars, etc.
Rated output current	100A	200A	80A	150A
Output Voltage Range	42-240Vdc (parameters adjustable)		200-1000Vdc (parameters adjustable)
Voltage stabilization accuracy	≤±0.5%
Wind Turbine Input Side
Rated voltage	48Vac-380Vac		380 Vac
Maximum withstand voltage	290Vac-530Vac for 5 seconds		600Vac for 5 seconds
MPPT voltage range	90~520V customized		220~530Vac
Maximum power	10kW	20kW	40kW	60KW
Rated Input Current	40Aac	80Aac	40Aac	80Aac
Input protection	Fuses; lightning protection circuits
Environmental Conditions
Ambient temperature	-25℃～50℃
Storage temperature	-40℃～75℃
Relative humidity	0 to 95%
Height above sea level	3000m full load output

Customization Options

Brand Name: Greef
Model Number: AHCC
Place Of Origin: CHINA
Certification: CE
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Foam+plywooden Case
Delivery Time: 25 Working Days
Payment Terms: T/T, Western Union, MoneyGram, L/C

Packaging & Shipping

The Off Grid Controller is securely packaged in a sturdy cardboard box with foam inserts for impact protection. Our eco-friendly packaging is designed for safe transit while being recyclable.

Orders are typically processed within 1-2 business days, with standard and expedited shipping options available through trusted carriers. Customers receive tracking information for shipment monitoring.

For system solutions tailored to your specific needs, please contact us.
