MPPT Off Grid Controller 40Aac/80Aac Input 100A-200A Output

DC bus bars off grid controller

off grid controller 40Aac input

off grid controller 100A output

Brand Name:

Greef

Certification:

Model Number:

AHCC

Request A Quote

Product Details

Method:

PWM/MPPT

Mppt Voltage Range:

90~520V/220~530Vac Customized

Maximum Withstand Voltage:

290Vac-530Vac/600Vac For 5 Seconds

Communication:

Standard: RS485/TCP

Height Above Sea Level:

3000m Full Load Output

Rated Voltage:

48Vac-380Vac

Type Of Energy Storage:

Lead-acid Batteries, Lithium Batteries, DC Bus Bars, Etc.

Rated Input Current:

40Aac/80Aac

Payment & Shipping Terms

Minimum Order Quantity

1Set

Price

Negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

Payment Terms

T/T,Western Union,MoneyGram,L/C

Supply Ability

MPPT Off Grid Controller AHCC 48-380V 5-30KW Wind Solar Hybrid

Get Best Price

Video

Greef AHCC Off Grid Controller 100A MPPT 90-520V RS485/TCP

Get Best Price

Video

AHCC Off Grid Controller MPPT 100A-200A with RS485/TCP Communication

Get Best Price

Video

MPPT Off Grid Controller 100A-200A Output for Wind Solar Systems

Get Best Price

Contact Now

Product Description

DC Bus Bars Off Grid Controller

Rated Input Current 40Aac/80Aac | Rated Output Current 100A/200A/80A/150A

The GREEF Off-grid Controller is a technologically advanced solution for wind generator systems, converting three-phase AC current from wind turbines into DC current to charge battery banks efficiently.

Key Features

Power Tracking: Wind energy MPPT with 98% engagement to actual wind energy output curve for enhanced power generation
Safety Protection: Comprehensive protection including over-voltage, over-current, anti-reverse connection, and short circuit
IOT Functionality: Wired network with APP remote view/control and remote data export capabilities
Touch Screen Interface: Displays voltage, current, power, generation status with alarm query and parameter adjustment
Custom Power Absorption: Modular, hot-swappable circuit with electrical isolation and wide input voltage range
PWM Unloading: Fan self-powered mode with soft unloading adjustment for safe turbine operation

Technical Specifications

Model	AHCC-5KW	AHCC-10KW	AHCC-20KW	AHCC-30KW
Rated power	5KW	10KW	20KW	30KW
Product Type	MPPT, high frequency isolated new energy converter
DC Output Side
Type of energy storage	Lead-acid batteries, lithium batteries, DC bus bars
Rated output current	100A	200A	80A	150A
Output Voltage Range	42-240Vdc (adjustable)		200-1000Vdc (adjustable)
Wind Turbine Input Side
Rated voltage	48Vac-380Vac		380Vac
Maximum power	10kW	20kW	40kW	60KW
Rated Input Current	40Aac	80Aac	40Aac	80Aac

Product Images

Applications

The AHCC Off-Grid Controller is compatible with various off-grid power generation systems including wind, hydroelectric, and solar power. It provides precise control over energy generation and storage to maximize system effectiveness.

Customization Options

We offer comprehensive customization services including:

Solar and wind controller options
DCS Distributed Control System integration
Wind controller capabilities
Branding options (Greef)
Certification compliance (CE)

Frequently Asked Questions

What is the brand name of the Off Grid Controller?

The product is branded as Greef.

What certifications does the product have?

The controller is CE certified.

What are the payment terms?

We accept T/T, Western Union, MoneyGram, and L/C.

System Solutions

We can tailor a system to your specific needs. Please contact us for more information about our products and customized solutions.
