Name: Without Transformer Off Grid Power Inverter with AC/DC Conversion and -40℃~+60℃ Ambient Temperature for Energy Storage Systems
Brand: Qingdao Greef New Energy Equipment Co., Ltd
SKU: Mars
Price: 16,501.00 USD
Availability: InStock

Home > Products > Off Grid Power Inverter >

Without Transformer Off Grid Power Inverter with AC/DC Conversion and -40℃~+60℃ Ambient Temperature for Energy Storage Systems

Without Transformer Off Grid Power Inverter

AC/DC Conversion Energy Storage Inverter

-40℃~+60℃ Ambient Temperature Power Conversion System

Brand Name:

Greef

Certification:

Model Number:

Mars

Request A Quote

Product Details

Frequency:

50/60Hz

Topology:

Without Transformer

Ambient Temperature:

-40℃~+60℃

Maximum Efficiency:

98.9%

Minim Um DC Voltagel'1:

Rated Grid Voltage:

400V

DC Voltage Operating Range:

580-1000 V

Maximum DC Voltage:

1,000V

Highlight:

Without Transformer Off Grid Power Inverter

AC/DC Conversion Energy Storage Inverter

-40℃~+60℃ Ambient Temperature Power Conversion System

Payment & Shipping Terms

Minimum Order Quantity

1Set

Price

Negotiable

Delivery Time

15-25Days

Payment Terms

T/T Paypal D/P Money Gram

Supply Ability

400 Sets/month

Intelligent Air Cooling Off Grid Power Inverter with 580V Minimum DC Voltage and LCD Smart Touch Screen for Remote Renewable Energy Systems

Get Best Price

Off Grid Power Inverter with Ambient Temperature -40 to +60 Degrees Featuring DC Output and LCD Smart Touch Screen Display

Get Best Price

98.9% Maximum Efficiency Stand-alone Inverter System with 174A/192A/217A Maximum DC Current and LCD Smart Touch Screen for Off Grid Power Supply

Get Best Price

Intelligent Air Cooling Off Grid Power Inverter with 98.9% Maximum Efficiency and 300-460V Permissible Grid Voltage Range

Get Best Price

Contact Now

Product Description

Without Transformer On/Off-grid Electricity Inverter Power Conversion System

Product Features

Product Parameters

Model	Mars-100kt	Mars-110kt	Mars-125kt
Maximum DC voltage	1,000v
Minimum DC voltage	580V
DC voltage operating range	580-1000v
Maximum DC current	173A	190A	216A
Rated charging/discharging power	100kw	110kW	125kW
Maximum charge and discharge power	120kw	132kW	150kW
Rated charge and discharge current	145A	160A	182A
Maximum charge-discharge current	174A	192A	217A
Rated grid voltage	400V
Permissible grid voltage range	300-460v
Rated grid frequency	50Hz/60Hz
Current total harmonic distortion rate	<3% (at rated power)
Power factor	>0.99
Power factor range	-1~1
Overload capacity	1.2 Pn,continuous for 1 minute
Rated input voltage	400V
Voltage deviation	±2%
Total harmonic distortion rate	<3% (linear load)

Product Description

The Power Conversion Inverter serves as the central component in energy storage systems, functioning as the "brain" of the setup. It efficiently converts power between alternating current (AC) and direct current (DC), enabling effective energy management and distribution.

Key Functions

AC/DC Conversion (Rectification/Inversion):
- Charging (AC → DC): Converts surplus grid power or AC from PV inverters into DC electricity for battery storage
- Discharging (DC → AC): Transforms stored DC power from batteries into AC power for grid supply or equipment use
Dual-Mode Operation: Supports seamless transition between grid-tied and off-grid modes for flexible energy management

Applications

The Power Conversion System (PCS) enables energy storage systems to operate in both grid-connected and independent microgrid configurations, providing reliable power solutions for various applications.

Customization Options

Brand: Greef
Model: Mars series
Origin: China
Certification: CE
MOQ: 1 Set
Supply Capacity: 400 Sets/month
Custom Configurations: Stand-alone Inverter System, Independent Energy Inverter

Support and Services

Our comprehensive support package includes technical assistance, installation guidance, troubleshooting, warranty services, and maintenance support to ensure optimal inverter performance and customer satisfaction.

Packing and Shipping

The inverter is securely packaged with bubble wrap in sturdy cardboard boxes for safe transportation. Orders are dispatched within 24 hours with tracking information provided.

Frequently Asked Questions

What is the brand name of this off-grid power inverter?

The brand name is Greef.

What is the model number of this off-grid power inverter?

The model number is Mars.

Where is this off-grid power inverter manufactured?

It is manufactured in China.

What certification does this off-grid power inverter have?

It is CE certified.

What are the accepted payment terms?

We accept T/T, Paypal, D/P, and Money Gram.
