Name: LCD Touch Screen On Grid Controller with Grid Monitoring and 5 Years Warranty for Energy Management Solutions
Brand: Qingdao Greef New Energy Equipment Co., Ltd
SKU: AC PCS
Price: 1,730.00 USD
Availability: InStock

Home > Products > On Grid Controller >

LCD Touch Screen On Grid Controller with Grid Monitoring and 5 Years Warranty for Energy Management Solutions

LCD Touch Screen On Grid Controller

5 Years Warranty Energy Management Controller

Grid Monitoring Generator Hybrid Converter

Brand Name:

Greef

Certification:

Model Number:

AC PCS

Request A Quote

Product Details

Warrantyperiod:

5 Years

Manual Function:

Manual Brake, Reset, Emergency Switch

Efficiency:

≥98%

Application:

Wind Turbine

Grid Monitoring:

Yes

Protectionfeatures:

Overvoltage, Overcurrent, Short Circuit, Anti-Islanding

Output Type:

AC-to-DC

Lcd:

LCD Touch Screen

Payment & Shipping Terms

Minimum Order Quantity

1Set

Price

Negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

Payment Terms

T/T,Western Union,MoneyGram,L/C

Supply Ability

High-Efficiency On Grid Controller with Lithium-ion Battery and 5-Year Warranty for Grid Connection

Get Best Price

Video

98% Efficiency On Grid Controller with LCD Touch Screen and 5-Year Warranty for Wind Turbine Control

Get Best Price

Video

High Efficiency On Grid Controller with Lithium-ion Battery and LCD Touch Screen for Energy Management

Get Best Price

Video

Lithium-ion Battery On Grid Controller with LCD Touch Screen and 95% Maximum Efficiency for Solar and Wind Systems

Get Best Price

Contact Now

Product Description

LCD Touch Screen On Grid Controller with Grid Monitoring

Advanced energy control solution featuring a 5-year warranty period for reliable power management.

Product Overview

The GREEF ENERGY multi-functional converter integrates multiple essential functions into a single, efficient device. It performs AC-to-DC rectification specifically optimized for permanent magnet generators, supports comprehensive battery charging capabilities, and delivers reliable DC-to-AC inversion.

Featuring a dual LCD touchscreen with customizable interfaces, this converter utilizes advanced technology to maintain stable voltage and frequency control for permanent magnet synchronous generators (PMSGs), ensuring consistent and uninterrupted power supply to connected loads.

The system can be configured for grid-tied operation, enabling synchronization with electrical grids and supporting grid charging functionality for enhanced versatility across various energy system configurations.

Key Features

EMS Smart Energy Management System with configurable off-grid, grid-tied, and grid charging modes
Double LCD smart touch screen display for intuitive monitoring and control
Advanced generator power curve tracking technology for efficient power output management
AC/DC dual backup functionality for reliable auxiliary power supply
Control technology for managing unbalanced power loads
Standard RS485 Modbus RTU protocol for communication and integration
Optional PMW dump load over-voltage and over-speed protection
Optional water gate motor control for specialized applications
WIFI and LAN remote monitoring and control via dedicated app
Customizable sensor control functions for specific requirements
Optional Static Transfer Switch (STS) for seamless grid-tie to off-grid transitions

Technical Specifications

Parameter	Specification
Model	Mars-100kt
Rated Power Output	100 kW
Rated AC Voltage	≥320 V AC (Optimal: 450 V AC)
AC Voltage Working Range	240 V - 550 V
Maximum AC Current	180 A
Battery Voltage Range	350 V - 450 V DC
Rated Battery Voltage	400 V DC
Max Charging/Discharging Current	250 A
Rated Grid Voltage	400 V (Range: 300 V - 460 V)
Grid Frequency	50 Hz / 60 Hz
Maximum Efficiency	95%

Applications

The GREEF ENERGY multi-functional converter delivers versatile, intelligent power management across diverse applications requiring reliable energy solutions.

Renewable Energy Systems: Ideal for integrating Permanent Magnet Synchronous Generators (PMSGs) from wind turbines or hydro turbines into off-grid or hybrid systems, ensuring stable AC power delivery.

Off-Grid and Backup Power: Serves as the central hub for power conversion and management in standalone setups including remote sites, cabins, and telecommunications stations.

Grid-Interactive Systems: Supports grid-tied operations for battery charging from the grid or potential surplus power feedback, subject to local regulations.

Industrial and Commercial Power Management: Provides consistent power delivery under varying load conditions with remote monitoring via WIFI/LAN and Modbus protocol integration.

Specialized applications include optional water gate motor control for micro-hydropower plants and Static Transfer Switch (STS) integration for seamless mode transitions.

Customization & Ordering

Greef offers customizable AC PCS On Grid Controllers designed and manufactured in China with CE certification. These Generator Hybrid Converters feature DC-DC switching controllers and precise monitoring of wind turbine speed and wind conditions for optimal performance.

Supporting 50Hz/60Hz output frequency and AC-to-DC conversion, these units ensure seamless integration with your energy systems. Minimum order quantity is 1 set with negotiable pricing.

Each unit is securely packaged with foam and plywood cases for safe delivery within 25 working days. Payment options include T/T, Western Union, MoneyGram, and L/C.

Backed by a 5-year warranty, the AC PCS On Grid Controller includes comprehensive protection features: overvoltage, overcurrent, short circuit, and anti-islanding safeguards.
