NdFeB Permanent Magnet Generator
Product Overview
The fundamental concept behind a permanent magnet generator lies in the rotor containing permanent magnet materials that produce a steady magnetic field. This constant magnetic flux is a key feature that differentiates it from other types of generators.
When the rotor is set into motion by a prime mover, such as a wind turbine, water turbine, or an engine, the magnetic field created by the magnets rotates along with the rotor. This rotating magnetic field then interacts with the conductors located in the stator windings.
Based on the law of electromagnetic induction, the movement of the magnetic field relative to the stationary coils induces an electromotive force (EMF) within the stator windings. When these windings are connected to an external load or circuit, electrical energy is generated and can be harnessed for practical use.
Key Features
- High efficiency with optimal performance and minimal energy consumption
- High power factor maximizing effective use of electrical power
- Compact design with high power density
- Large starting pitch for smooth and reliable startup performance
- Low noise operation and low temperature rise
- Reliable consistent operation over extended periods
- Smooth torque and speed control with high mechanical stability
Technical Parameters
| Parameter |
Specification |
| Generator Shell Material |
Cast Iron |
| Winding Method |
Y |
| Magnet Type |
NdFeB |
| Winding Material |
100% Copper |
| Warranty |
3 Years |
| Rated Voltage |
12VAC - 1140VAC |
| Insulating Resistance |
100Mohm Min (500Vdc) |
| Type |
Electrical Generator |
| Shaft Type |
Vertical/Horizontal |
| Cooling Method |
Fan/Water/Self Cooling |
Applications
Permanent Magnet Generators (PMGs) are widely recognized for their exceptional efficiency, reliability, and compact design. These characteristics have made them the preferred choice for power generation across various modern industrial sectors.
- Wind Power Generation: Core component in direct-drive and semi-direct-drive wind turbines with outstanding efficiency at variable speeds
- Marine and Offshore: High reliability with minimal maintenance for ship shaft generators and vessel power systems
- Backup Power: Integral to diesel and gas generator sets for quick response and stable emergency power
- High-Speed Applications: Ideal for microturbines and flywheel energy storage systems
- Special-Purpose Industrial: Chosen for high power density and unparalleled reliability in demanding environments
Customization Options
Greef offers customized Permanent Magnet Generator solutions under the model number GDF, originating from China. Our generators are certified with CE and classified with an IP54 degree of protection, ensuring reliable performance in various environments.
These three phase, 3 Phase AC Permanent-magnet generators are designed to operate efficiently at LOW SPEED, making them ideal for a wide range of applications. The power range spans from 500W to 5000kW, providing flexible options to meet your specific energy needs.
- Vertical and horizontal shaft types available
- High-quality SKF bearings for durability and smooth operation
- Minimum order quantity: 1 set
- Negotiable pricing based on project scope
- Secure packaging with foam and plywood cases
- Delivery time: Approximately 25 working days
- Payment terms: T/T based
Packing and Shipping
Our Permanent Magnet Generator is carefully packaged to ensure it arrives safely and in perfect working condition. Each unit is securely wrapped with protective materials to prevent damage during transit.
The generator is placed in a sturdy, custom-designed cardboard box that provides excellent cushioning and support. Additional padding, such as foam inserts or bubble wrap, is used to safeguard delicate components.
For shipping, we use reliable carriers with tracking options to guarantee timely delivery. All packages are clearly labeled with handling instructions and are compliant with international shipping standards.
We recommend inspecting the package upon arrival and reporting any damages immediately to ensure prompt resolution.
