Place of Origin:
Qingdao, China
Brand Name:
GREEF
Certification:
CE, ISO9001
Model Number:
GPM-TP-132M
Video
Video
Motor burnout caused by overheating is one of the most common causes of production failure. This GREEF permanent magnet synchronous motor integrates PTC thermistors embedded in the winding, continuously monitoring temperature and triggering the protection relay before damage occurs. Combined with IP55 enclosure and Class F/H insulation, it offers reliable protection in harsh working conditions.
| Rated Power | 1.5-75 kW |
| Rated Voltage | 380V / 400V |
| Thermal Protection | PTC 150°C (optional PT100/PT1000) |
| Protection Class | IP55 |
| Insulation Class | F / H |
| Winding Material | 100% copper |
| Temperature Rise | ≤ 80K (Class F) |
| Cooling Method | IC411 |
| Mounting Type | IMB3 / IMB5 / IMB35 |
PTC trip temperature (130-180°C), PT100/PT1000 RTD sensors, anti-condensation heater and special tropical treatment can be added according to your protection requirements.
