IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range

IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range

Class F Insulation Permanent Magnet Motor

Y Winding Method 3-phase AC Synchronous Motor

500-3000rpm Speed Range Brushless DC Motor

Brand Name:

Greef

Certification:

CE

Model Number:

TYP

Contact Us
Request A Quote
IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range
IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range
Product Details
Winding Method:
Y
Speed:
500-3000rpm
Winding Material:
100% Copper
Generator Type:
3phase AC Synchronous Motor
Shaft Material:
Steel
Insulation Class:
Class F
Insulationclass:
Class F
Insulating Resistance:
100Mohm Min(500Vdc)
Highlight:

Class F Insulation Permanent Magnet Motor

,

Y Winding Method 3-phase AC Synchronous Motor

,

500-3000rpm Speed Range Brushless DC Motor

Payment & Shipping Terms
Minimum Order Quantity
1Set
Price
Negotiable
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Payment Terms
T/T,Western Union,,L/C
Supply Ability
Supply Ability
RELATED PRODUCTS
Good price IP54 Brushless Permanent Magnet Motor with NdFeB Magnet and Class F Insulation for Industrial Applications online Video

IP54 Brushless Permanent Magnet Motor with NdFeB Magnet and Class F Insulation for Industrial Applications

Get Best Price
Good price Class F Insulation Permanent Magnet Motor with 50/60HZ Frequency for Heavy Industrial Applications online Video

Class F Insulation Permanent Magnet Motor with 50/60HZ Frequency for Heavy Industrial Applications

Get Best Price
Good price 500W-5000KW Permanent Magnet Motor with 500-3000rpm Speed Range and Class F Insulation for Industrial Applications online Video

500W-5000KW Permanent Magnet Motor with 500-3000rpm Speed Range and Class F Insulation for Industrial Applications

Get Best Price
Good price IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range online Video

IP54 Permanent Magnet Motor with Class F Insulation and Y Winding Method for 500-3000rpm Speed Range

Get Best Price
Contact Us
Contact Now
Product Description
IP54 Permanent Magnet Motor with Y Winding and Class F Insulation
External view of permanent magnet motor Internal components of permanent magnet motor Stator assembly of permanent magnet motor Rotor detail of permanent magnet motor Complete assembly of permanent magnet motor
Product Description
A permanent magnet motor is an electric motor that utilizes permanent magnets instead of field windings to create the primary magnetic field. This design distinguishes it from traditional motors that rely on electrically generated magnetic fields.
The fundamental operating principle involves the interaction between the permanent magnets mounted on the rotor and the rotating magnetic field produced by the energized windings of the stator. This interaction generates the necessary driving torque to power the motor.
Compared to conventional motors requiring electrical excitation, permanent magnet motors eliminate the need for excitation current, resulting in a simpler and more dependable design. These motors are generally more compact and lighter in weight, while the removal of copper losses in the field circuit contributes to considerable energy savings and higher efficiency.
Key Features
  • High efficiency and energy-saving capabilities for optimal performance with minimal power consumption
  • Consistent torque across wide speed range for reliable operation under various conditions
  • Long bearing life with low maintenance requirements, reducing downtime and costs
  • High-performance permanent magnets for superior magnetic strength and efficiency
  • Integrated thermal protection to prevent overheating during extended use
  • Synchronous operation capability for stable speed control and precise regulation
  • Low operating current requirements reducing electrical load and enhancing safety
  • Lower temperature rise during operation maintaining optimal working conditions
  • Broad application range across numerous industries and functions
  • Significant cost savings through efficiency, durability, and low maintenance
Technical Parameters
Insulation Class Class F
Speed 500-3000 rpm
Magnet Type NdFeB (Neodymium Magnet)
Winding Method Y
Shaft Material Steel
Insulating Resistance 100 Mohm Min (500 Vdc)
Generator Shell Material Cast Iron
Winding Material 100% Copper
Generator Type 3-phase AC Synchronous Motor
Applications
The TYP series high-efficiency permanent magnet frequency conversion synchronous motors are renowned for their exceptional performance and energy-saving capabilities, providing reliable operation across various industrial applications.
  • Injection molding machines
  • Air compressors
  • Pipe making equipment and hydraulic machinery
  • Food machinery
  • Cement pipe manufacturing machines
  • Plastic extruders and wire drawing machines
  • Pharmaceutical equipment
Customization Options
Greef offers customized Permanent Magnet Electric Motors designed to meet specific requirements. Our TYP model, manufactured in China, is CE certified with power output ranging from 500W to 5000KW.
The generator shell features durable cast iron construction with IP54 protection rating. The iron core uses cold rolled silicon steel sheet for excellent magnetic properties, with Class F insulation ensuring long-lasting thermal endurance.
Minimum order: 1 set | Negotiable pricing | Packaging: foam and plywood cases | Delivery: 25 working days | Payment: T/T, Western Union, , L/C
Packing and Shipping
Each motor is securely wrapped in anti-static foam and placed in custom-fitted cardboard boxes, then packed in sturdy outer cartons with additional cushioning. All packages are clearly labeled with handling instructions.
Multiple shipping options available including air freight, sea freight, and express courier services with real-time tracking to ensure timely arrival and perfect working condition upon delivery.
