Insulate Grade H Permanent Magnet Generator with Copper Stator and Power Factor 0.8 for Renewable Energy

Insulate Grade H Permanent Magnet Generator with Copper Stator and Power Factor 0.8 for Renewable Energy

Copper Stator Permanent Magnet Generator

Power Factor 0.8 PMG

Insulate Grade H Synchronous Generator

Brand Name:

Greef

Certification:

CE

Model Number:

GDF

Contact Us
Request A Quote
Insulate Grade H Permanent Magnet Generator with Copper Stator and Power Factor 0.8 for Renewable Energy
Insulate Grade H Permanent Magnet Generator with Copper Stator and Power Factor 0.8 for Renewable Energy
Product Details
Magnet Type:
NdFeB
Frequency:
50Hz/60Hz
Winding Method:
Y
Rated Voltagee:
Custmoized
Generator Type:
3phase AC Synchronous Generator
Power Factor:
0.8
Installation:
Horizontal/Vertical
Power Range:
500W-5000kw
Highlight:

Copper Stator Permanent Magnet Generator

,

Power Factor 0.8 PMG

,

Insulate Grade H Synchronous Generator

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Payment Terms
T/T
RELATED PRODUCTS
Good price High Insulating Resistance 100Mohm Min 500Vdc Permanent Magnet Generator with NdFeB Magnet Type and Rated Speed 20-3000rpm online Video

High Insulating Resistance 100Mohm Min 500Vdc Permanent Magnet Generator with NdFeB Magnet Type and Rated Speed 20-3000rpm

Get Best Price
Good price 20-3000rpm Permanent Magnet Generator with Customized Voltage Options and NdFeB Magnet for Automation online Video

20-3000rpm Permanent Magnet Generator with Customized Voltage Options and NdFeB Magnet for Automation

Get Best Price
Good price 3 Phase AC Synchronous Permanent Magnet Generator with Y Winding Method and Durable Aluminium Alloy Blade for Customized Voltage Applications online Video

3 Phase AC Synchronous Permanent Magnet Generator with Y Winding Method and Durable Aluminium Alloy Blade for Customized Voltage Applications

Get Best Price
Good price Insulate Grade H Permanent Magnet Generator with NdFeB Magnet and 20-3000rpm Rated Speed for Industrial Equipment online Video

Insulate Grade H Permanent Magnet Generator with NdFeB Magnet and 20-3000rpm Rated Speed for Industrial Equipment

Get Best Price
Contact Us
Contact Now
Product Description
Insulate Grade H Permanent Magnet Generator
Permanent Magnet Generator technical diagram Permanent Magnet Generator internal components Permanent Magnet Generator assembly view Permanent Magnet Generator rotor detail Permanent Magnet Generator stator winding Permanent Magnet Generator complete unit
Product Overview
The fundamental concept behind a permanent magnet generator is that its rotor contains permanent magnet materials which create a steady magnetic field. This magnetic field remains constant as the rotor spins.
When a prime mover, such as a wind turbine, water turbine, or engine, causes the rotor to turn, the magnetic field produced by the permanent magnets rotates along with it. This rotating magnetic field interacts with the stator windings surrounding the rotor.
As the magnetic field cuts through the conductors in the stator windings, electromagnetic induction occurs. This process induces an electromotive force within the stator coils. When an external electrical circuit is connected to the generator, this induced voltage drives a current, allowing the generator to deliver electrical power.
Key Features
  • Outstanding Performance: Exceptional efficiency with optimal performance and energy conservation capabilities
  • Compact and Powerful Design: High power density in a small footprint for space-constrained applications
  • Enhanced Operational Qualities: High power factor and large starting torque for smooth acceleration
  • Silent and Cool Operation: Low noise levels and minimal temperature rise for comfortable operation
  • Reliability and Precision: Consistent performance with smooth torque and speed characteristics
Technical Specifications
Stator Material Copper
Frequency 50Hz/60Hz
Rated Voltage Customized
Insulate Grade H
Generator Type 3 phase AC Synchronous Generator
Power Range 500W - 5000kW
Installation Horizontal/Vertical
Insulating Resistance 100Mohm Min (500Vdc)
Magnet Type NdFeB
Power Factor 0.8
Special Feature LOW START TORQUE, Permanent Magnet Generator, three phase
Applications
  • Wind Power Generation: Core component in direct-drive and semi-direct-drive wind turbines with superior efficiency during variable-speed operations
  • New Energy Vehicles: Main traction units or auxiliary generators in electric and hybrid vehicles
  • Marine Applications: Ship shaft generators and main/auxiliary power systems with high reliability
  • Backup Power Systems: Diesel and gas generator sets for emergency and standby power
  • High-Speed Applications: Microturbines and flywheel energy storage systems
  • Industrial Sectors: Special-purpose applications requiring high power density and exceptional reliability
Customization Options
Greef offers customized Permanent Magnet Generator (PMG) solutions under model number GDF, designed to meet specific power requirements from 500W to 5000kW. Our three phase AC synchronous generators provide reliable and efficient power generation with low start torque for smooth operation.
Key Customization Details:
• Manufactured in China with high-quality aluminium alloy blades
• Rated speed: 20 to 3000rpm for versatile applications
• CE certification for international standards compliance
• Minimum order quantity: 1 set
• Packaging: Secure foam and plywooden cases
• Delivery: 25 working days
• Payment: Flexible T/T terms
Packaging and Shipping
Our Permanent Magnet Generators are carefully packaged to ensure maximum protection during transit. Each unit is securely enclosed in custom-fitted foam within sturdy, double-walled corrugated cardboard boxes to prevent movement or damage.
Packaging includes moisture-resistant materials and shock-absorbing layers for environmental protection. All packages are clearly labeled with handling instructions and product details.
Shipping options include air freight, sea freight, and ground transportation via reliable logistics partners. Each generator undergoes thorough quality inspection and functional testing before shipment. Tracking information is provided upon dispatch.
